Zusätzliche Information
| Rahmen | Zendit Stealth Air full Carbon, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers. |
|---|---|
| Material | Carbon |
| Gewicht | 22,8 kg |
| zulässiges Gesamtgewicht | 150 Kg |
| Gabel | Fox 38 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 15x110mm Kabolt axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload. |
| Dämpfer | Dämpfer Fox Float X Factory Kashima Evol LV 205x65mm. 2-positions lever compresion (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings. |
| Schaltwerk | Sram S1000 Eagle AXS, T-Type, 12s |
| Kurbel | e*thirteen Helix Core e*spec alloy. All sizes: 155mm |
| Kassette | Sram XS 1270, 10-52T, T-Type, 12s |
| Felgen | DT Swiss Hybrid H 1900 SPLINE, aluminum, hooked / crotchet tubeless TC, 30mm internal width, tubeless ready, 28 spokes. |
| Naben | vorne: DT Swiss 370, 15x110mm Boost, Disc IS (6-bolt)., hinten: DT Swiss 370, 12x148mm Boost, Disc IS (6-bolt), Sram XD Steel (SSRAM) freehub body, Ratchet LN 18 freehub system. |
| Radgröße | 27,5 Zoll / 29 Zoll |
| Bereifung | vorne: Maxxis Assegai 29×2.5WT, tubeless ready, 3C Maxx Grip compound, EXO+ protection, 60TPI, folding bead, hinten: Maxxis Minion DHR II 27.5×2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead |
| Motor | Avinox |
| max. Drehmoment | 130 Nm Drehmoment, 150 Nm im Boost-Modus |
| Reichweite | bis zu 150 km |
| Unterstützung | bis zu 25 km/h |
| Akku | Avinox 800Wh Battery |
| Display | Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R) |
| Bremsen | Sram Maven Base, 18-millimeter 4 piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads. |
| Lenker | Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise. |
| Sattelstütze | Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm). |
| Sattel | Ergon SM10 E-Mountain Black. |
| Vorbau | Onoff S9 30mm 0º, Full CNC, 31.8mm barbore. |
| Sonstiges | Ladegerät im Lieferumfang enthalten |
| Rahmenhöhe |
